short info

Soil Cone Penetrometer is Used For determining the liquid limit of soils. This is especially useful to obtain reliable and accurate results of those soil that have a low plasticity index.

Standard

IS : 2720 (Part 5) BS 1377

Model

VSLIC-S198

Origin

Indian

Make/ OEM

VERTEX

  • Description

  • SPECIFICATIONS

  • FEATURES

  • VIDEO
  •  New
    WORKING PRINCIPAL

OVERVIEW

It is applicable to a wider range of soils. The test is based on the relationship between moisture content and the penetration of the cone into the soil sample. The moisture content at a given depth of penetration of the cone is taken as the liquid limit.
For determining the liquid limit of soils. This is especially useful to obtain reliable and accurate results of those soil that have a low plasticity index.
The percentage moisture contents determined when cone with half angle of 15-30 minutes under a total sliding weight of 148 gm penetrates 25mm gives the liquid limit



SPECIFICATIONS

Soil Cone Penetrometer for Liquid Limit is complete with an automatic controller, which automatically releases the plunger by a magnetic device, complete with micrometer vertical adjustment and adjustable electronic timer of the fall time. The penetrometer is equipped with a digital timer, which can be set to the standard 5 second free-fall time or to some other setting for customized tests. When engaged the timer will allow the needle to free fall into the sample for the specific time interval and then lock the needle from advancing while providing a direct reading of the test results.

FEATURES

320 g weight should be added to the 30° angle cone to get a total weight of 400 g for the shear strength test.
Semi-Automatic Penetrometer for Liquid Limit supplied complete with 30° Penetration Cone, Sample Cups, 3 pcs. Aluminum.
