Pipe Fitting Apparatus VSLIC-FM15

short info

Pipe Fitting Apparatus. The setup consists of a 1/2 bend and elbow, a sudden expansion sudden contraction fitting from 15mm to 25mm, ball valve, and gate valve. Pressure tapings are provided at the inlet and outlet of these fittings under test. A differential manometer fitted in the line gives pressure loss of individual fittings. The set-up can be connected to Hydraulic Bench by flexible pipeline.

Model

VSLIC-FM15

Origin

Indian

Make/ OEM

VERTEX

get a quote

  • Description

  • SPECIFICATIONS

  • FEATURES

  • VIDEO
  •  New
    WORKING PRINCIPAL

OVERVIEW

Pipe Fitting Apparatus. The setup consists of a 1/2 bend and elbow, a sudden expansion sudden contraction fitting from 15mm to 25mm, ball valve, and gate valve. Pressure tapings are provided at the inlet and outlet of these fittings under test. A differential manometer fitted in the line gives pressure loss of individual fittings. The set-up can be connected to Hydraulic Bench by flexible pipeline.

Learning Objectives/Experiments:

  • To determine loss of head in the fittings at various water flow rates.
  • To determine the loss co-efficient for the pipe fittings.
  • Comparing the Pressure drop across each device.

Specifications:

  • Bend: 1/2″
  • Elbow: 1/2″
  • Ball valve: 1/2″
  • Gate valve: 1/2″
  • The whole set-up is ingeniously designed and schematically arranged on a powder-coated rigid structure
