Cement Flow Table, Motorised VSLIC-C108

short info

Used for determining the workability of building lime.

It comprises :

  • One 300 mm dia polished steel table with three engraved circles of 70 mm, 110 mm and 190 mm dia at the top face.
  • A frame having a horizontal shaft carrying a cam on one side and a wheel on the other, adjusted to raise the table by 12.5 mm and allow it to fall freely.

Standard

IS 1199-1959, ASTM C-124, AASHTO-T-120.

Model

VSLIC-C108

Origin

Indian

Make/ OEM

VERTEX

get a quote

  • Description

  • SPECIFICATIONS

  • FEATURES

  • VIDEO
  •  New
    WORKING PRINCIPAL

OVERVIEW

Used for determining the workability of building lime.

It comprises :

  • One 300 mm dia polished steel table with three engraved circles of 70 mm, 110 mm and 190 mm dia at the top face.
  • A frame having a horizontal shaft carrying a cam on one side and a wheel on the other, adjusted to raise the table by 12.5 mm and allow it to fall freely.
  • Truncated conical mould 65 mm inside dia at the bottom, 40 mm inside dia at top and 90 mm high.
  • A machined table top 250 mm dia of Gun metal fitted with a vertical shaft. Total weight 4.00 ± 0.05 kg.
  • A cast iron frame with a machined base and a smooth vertical hole at the top for the table shaft. It has a horizontal shaft carrying a cam at one end and a hand wheel at the other. The cam allows 12 mm free drop of the table.
  • A conical mould 100 mm inside dia at bottom, 70 mm inside dia at top and 50 mm high.

Same as VSLIC-C107 but provided with a motor drive for operation of the cam at about 60 r.p.m. to give approximately one drop per second to the table top.

Suitable for operation on 220 V, 50 Hz, Single phase supply.


Related Searches

SPECIFICATIONS

Used for determining the workability of building lime.

It comprises :

  • One 300 mm dia polished steel table with three engraved circles of 70 mm, 110 mm and 190 mm dia at the top face.
  • A frame having a horizontal shaft carrying a cam on one side and a wheel on the other, adjusted to raise the table by 12.5 mm and allow it to fall freely.
  • Truncated conical mould 65 mm inside dia at the bottom, 40 mm inside dia at top and 90 mm high.
  • A machined table top 250 mm dia of Gun metal fitted with a vertical shaft. Total weight 4.00 ± 0.05 kg.
  • A cast iron frame with a machined base and a smooth vertical hole at the top for the table shaft. It has a horizontal shaft carrying a cam at one end and a hand wheel at the other. The cam allows 12 mm free drop of the table.
  • A conical mould 100 mm inside dia at bottom, 70 mm inside dia at top and 50 mm high.

Same as VSLIC-C107 but provided with a motor drive for operation of the cam at about 60 r.p.m. to give approximately one drop per second to the table top.

Suitable for operation on 220 V, 50 Hz, Single phase supply.

FEATURES

Used for determining the workability of building lime.

It comprises :

  • One 300 mm dia polished steel table with three engraved circles of 70 mm, 110 mm and 190 mm dia at the top face.
  • A frame having a horizontal shaft carrying a cam on one side and a wheel on the other, adjusted to raise the table by 12.5 mm and allow it to fall freely.
  • Truncated conical mould 65 mm inside dia at the bottom, 40 mm inside dia at top and 90 mm high.
  • A machined table top 250 mm dia of Gun metal fitted with a vertical shaft. Total weight 4.00 ± 0.05 kg.
  • A cast iron frame with a machined base and a smooth vertical hole at the top for the table shaft. It has a horizontal shaft carrying a cam at one end and a hand wheel at the other. The cam allows 12 mm free drop of the table.
  • A conical mould 100 mm inside dia at bottom, 70 mm inside dia at top and 50 mm high.

Same as VSLIC-C107 but provided with a motor drive for operation of the cam at about 60 r.p.m. to give approximately one drop per second to the table top.

Suitable for operation on 220 V, 50 Hz, Single phase supply.
